Depicts the exact location and dimensions of an easement across a parcel.
Prepared and sealed by a licensed Illinois Professional Land Surveyor.
Supports utility, drainage, ingress-egress, and other easement purposes on your land.
Formatted for any required approvals and recording with the county Recorder of Deeds.
We define the exact location, width, and extent of the easement relative to the property boundary.
The plat includes a clear legal description so the easement can be recorded and gives notice to future owners.
Each Plat of Easement is signed and sealed by an Illinois Professional Land Surveyor as required for recording.
We prepare the plat to the format and review standards of utilities, municipalities, and counties across Chicagoland.
Pi Surveying provides land surveys for both the private and commercial sector.
Get started on your next project with Pi Surveying’s expert land surveying services. Contact us today to schedule your survey and get accurate and reliable results.
Don’t take our word for it. Here’s what clients have to say…
Find answers to commonly asked questions about ALTA/NSPS Land Title Surveys, providing clarity and information for property transactions.
An easement grants a right to use a defined portion of land for a specific purpose, while ownership remains with the property owner. The plat depicts the area subject to that right.
Easements are commonly recorded so they give notice to lenders, title companies, and future owners. Recording requirements depend on the parties and the applicable county practice.
We prepare plats for utility, access and ingress-egress, and drainage or stormwater easements, among others, defining each with a precise boundary and legal description.
